Climbing

  -

Straight Walls

Straight walls can be formed using any one of the four Form-Scaff wall formwork systems.  The crane handled Tifa system can withstand a concrete pressure of 60kN/m2 and can be gang-formed up to a size of 26m2.

The Tifa-Lite system is a man handled system, can withstand a concrete pressure of 60kN/m2 and can be gang-formed up to a size of 26m2. The crane handled Multi-Form Wall system is a more versatile Plywood faced system and can be made to suit the dimensions of the wall.

The Econo-Form Wall system is a man handled system, can withstand a concrete pressure of 40kN/m2. The Econo-Form system can also be gang-formed up to a size of 30m2.   All the systems can be plumbed using the Tifa Push-Pull Propping system and will produce a "smooth" off-shutter finish.



Application Category:
