Shoring

Light Duty Modular support work can be created using the 42kN Kwik-Stage or Super-Scaff systems up to any practical height.

Light Duty Modular

Heavy Duty Modular support work can be created using the 80kN Super-Stage system up to a height of 40m.

Heavy Duty Modular

Form-Scaff's BS-0, BS-1 and BS-2 Props can be used as Light Duty support work for most of Form-Scaff's decking systems. The propping systems are quick and easy to install and allow easy access between the Props. Propping heights ranging between 1.8m and 4m can be achieved and can support loads of up to 45kN.

Light Duty Props

Form-Scaff's Alu-Up Props can be used as Medium Duty support work for most of Form-Scaff's decking systems.

Medium Duty Props

Form-Scaff's Form-Soldier 125kN Shores are best suited for supporting thick concrete slabs such as bridge decks up to a propping height of 11.6m. Form-Solders are bolted together end on end to form the required propping height and are braced together using scaffold tube and fittings.

Heavy Duty Props

Form-Scaff's 1000kN Super-Shores are used for propping heights up to 36.0m.

Ultra Heavy Duty Props

Form-Scaff supplies a wide range of support work equipment - from light duty modular systems to ultra heavy duty prop applications. The propping height and the applied load usually determines which system is best suited for each application.
